Table 308: GATE Output signals
Name Type Description
OUT BOOLEAN Output signal
Settings
Table 309: GATE Group settings (basic)
Name Values (Range) Unit Step Default Description
Operation Off
On
- - Off Operation Off/On
13.3.1.6 Exclusive OR function block XOR
Identification
Function description IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Exclusive OR function block XOR - -
Functionality
The exclusive OR function (XOR) is used to generate combinatory expressions with
boolean variables. XOR has two inputs and two outputs. One of the outputs is
inverted. The output signal is 1 if the input signals are different and 0 if they are the
same.
Function block
XOR
INPUT1
INPUT2
OUT
NOUT
IEC09000292-1-en.vsd
IEC09000292 V1 EN
Figure 221: XOR function block
Signals
Table 310: XOR Input signals
Name
Type Default Description
INPUT1 BOOLEAN 0 Input signal 1
INPUT2 BOOLEAN 0 Input signal 2
1MRK 502 048-UEN A Section 13
Logic
445
Technical manual
