Name Type Description
START1 BOOLEAN Start signal from stage 1
START2 BOOLEAN Start signal from stage 2
P REAL Active Power
PPERCENT REAL Active power in % of calculated power base value
Q REAL Reactive power
QPERCENT REAL Reactive power in % of calculated power base
value
8.7.2.4 Settings
Table 123: GOPPDOP Group settings (basic)
Name Values (Range) Unit Step Default Description
Operation Off
On
- - Off Operation Off / On
OpMode1 Off
OverPower
- - OverPower Operation mode 1
Power1 0.0 - 500.0 % 0.1 1.0 Power setting for stage 1 in % of
calculated power base value
Angle1 -180.0 - 180.0 Deg 0.1 0.0 Characteristic angle for stage 1
TripDelay1 0.010 - 6000.000 s 0.001 1.000 Trip delay for stage 1
OpMode2 Off
OverPower
- - OverPower Operation mode 2
Power2 0.0 - 500.0 % 0.1 1.0 Power setting for stage 2 in % of
calculated power base value
Angle2 -180.0 - 180.0 Deg 0.1 0.0 Characteristic angle for stage 2
TripDelay2 0.010 - 6000.000 s 0.001 1.000 Trip delay for stage 2
Table 124: GOPPDOP Group settings (advanced)
Name
Values (Range) Unit Step Default Description
k 0.00 - 0.99 - 0.01 0.00 Low pass filter coefficient for power
measurement, U and I
Table 125: GOPPDOP Non group settings (basic)
Name
Values (Range) Unit Step Default Description
GlobalBaseSel 1 - 6 - 1 1 Selection of one of the Global Base Value
groups
Mode L1, L2, L3
Arone
Pos Seq
L1L2
L2L3
L3L1
L1
L2
L3
- - Pos Seq Mode of measurement for current and
voltage
1MRK 502 048-UEN A Section 8
Current protection
233
Technical manual
