12.5.2 Functionality
The Selector mini switch VSGGIO function block is a multipurpose function used for
a variety of applications, as a general purpose switch.
VSGGIO can be controlled from the menu or from a symbol on the single line diagram
(SLD) on the local HMI.
12.5.3 Function block
VSGGIO
BLOCK
PSTO
IPOS1
IPOS2
BLOCKED
POSITION
POS1
POS2
CMDPOS12
CMDPOS21
IEC09000341-1-en.vsd
IEC09000341 V1 EN
12.5.4 Signals
Table 267: VSGGIO Input signals
Name
Type Default Description
BLOCK BOOLEAN 0 Block of function
PSTO INTEGER 0 Operator place selection
IPOS1 BOOLEAN 0 Position 1 indicating input
IPOS2 BOOLEAN 0 Position 2 indicating input
Table 268: VSGGIO Output signals
Name
Type Description
BLOCKED BOOLEAN The function is active but the functionality is
blocked
POSITION INTEGER Position indication, integer
POS1 BOOLEAN Position 1 indication, logical signal
POS2 BOOLEAN Position 2 indication, logical signal
CMDPOS12 BOOLEAN Execute command from position 1 to position 2
CMDPOS21 BOOLEAN Execute command from position 2 to position 1
Section 12 1MRK 502 048-UEN A
Control
418
Technical manual
