Name Type Description
UL31 REAL UL31 Amplitude
UL31RANG INTEGER UL31Amplitude range
UL31ANGL REAL UL31 Angle
14.1.4.4 Settings
Table 357: VMMXU Non group settings (basic)
Name Values (Range) Unit Step Default Description
Operation Off
On
- - Off Operation Off / On
GlobalBaseSel 1 - 6 - 1 1 Selection of one of the Global Base Value
groups
ULDbRepInt 1 - 300 Type 1 10 Cycl: Report interval (s), Db: In % of
range, Int Db: In %s
ULMax 0 - 4000000 V 1 170000 Maximum value
ULRepTyp Cyclic
Dead band
Int deadband
-
- Dead band Reporting type
ULAngDbRepInt 1 - 300 Type 1 10 Cycl: Report interval (s), Db: In % of
range, Int Db: In %s
Table 358: VMMXU Non group settings (advanced)
Name
Values (Range) Unit Step Default Description
ULZeroDb 0 - 100000 m% 1 500 Zero point clamping
ULHiHiLim 0 - 4000000 V 1 160000 High High limit (physical value)
ULHiLim 0 - 4000000 V 1 150000 High limit (physical value)
ULLowLim 0 - 4000000 V 1 125000 Low limit (physical value)
ULLowLowLim 0 - 4000000 V 1 115000 Low Low limit (physical value)
ULMin 0 - 4000000 V 1 0 Minimum value
ULLimHys 0.000 - 100.000 V 0.001 5.000 Hysteresis value in % of range and is
common for all limits
14.1.4.5 Monitored data
Table 359: VMMXU Monitored data
Name
Type Values (Range) Unit Description
UL12 REAL - kV UL12 Amplitude
UL12ANGL REAL - deg UL12 Angle
UL23 REAL - kV UL23 Amplitude
UL23ANGL REAL - deg UL23 Angle
UL31 REAL - kV UL31 Amplitude
UL31ANGL REAL - deg UL31 Angle
1MRK 502 048-UEN A Section 14
Monitoring
481
Technical manual
