IEC08000226-2-en.vsd
VNMMXU
U3P* UL1
UL1RANG
UL1ANGL
UL2
UL2RANG
UL2ANGL
UL3
UL3RANG
UL3ANGL
IEC08000226 V2 EN
Figure 240: VNMMXU function block
14.1.7.3 Signals
Table 370: VNMMXU Input signals
Name Type Default Description
U3P GROUP
SIGNAL
- Three phase group signal for voltage inputs
Table 371: VNMMXU Output signals
Name
Type Description
UL1 REAL UL1 Amplitude, magnitude of reported value
UL1RANG INTEGER UL1 Amplitude range
UL1ANGL REAL UL1 Angle, magnitude of reported value
UL2 REAL UL2 Amplitude, magnitude of reported value
UL2RANG INTEGER UL2 Amplitude range
UL2ANGL REAL UL2 Angle, magnitude of reported value
UL3 REAL UL3 Amplitude, magnitude of reported value
UL3RANG INTEGER UL3 Amplitude range
UL3ANGL REAL UL3 Angle, magnitude of reported value
14.1.7.4 Settings
Table 372: VNMMXU Non group settings (basic)
Name
Values (Range) Unit Step Default Description
Operation Off
On
- - Off Operation Mode On / Off
GlobalBaseSel 1 - 6 - 1 1 Selection of one of the Global Base Value
groups
UDbRepInt 1 - 300 Type 1 10 Cycl: Report interval (s), Db: In % of
range, Int Db: In %s
UMax 0 - 2000000 V 1 106000 Maximum value
Table continues on next page
Section 14 1MRK 502 048-UEN A
Monitoring
488
Technical manual
