14.1.6.4 Settings
Table 367: VMSQI Non group settings (basic)
Name
Values (Range) Unit Step Default Description
Operation Off
On
- - Off Operation Off / On
3U0DbRepInt 1 - 300 Type 1 10 Cycl: Report interval (s), Db: In % of
range, Int Db: In %s
3U0Min 0 - 2000000 V 1 0 Minimum value
3U0Max 0 - 2000000 V 1 318000 Maximum value
3U0RepTyp Cyclic
Dead band
Int deadband
-
- Dead band Reporting type
3U0LimHys 0.000 - 100.000 % 0.001 5.000 Hysteresis value in % of range and is
common for all limits
3U0AngDbRepInt 1 - 300 Type 1 10 Cycl: Report interval (s), Db: In % of
range, Int Db: In %s
U1DbRepInt 1 - 300 Type 1 10 Cycl: Report interval (s), Db: In % of
range, Int Db: In %s
U1Min 0 - 2000000 V 1 0 Minimum value
U1Max 0 - 2000000 V 1 106000 Maximum value
U1RepTyp Cyclic
Dead band
Int deadband
-
- Dead band Reporting type
U1AngDbRepInt 1 - 300 Type 1 10 Cycl: Report interval (s), Db: In % of
range, Int Db: In %s
U2DbRepInt 1 - 300 Type 1 10 Cycl: Report interval (s), Db: In % of
range, Int Db: In %s
U2Min 0 - 2000000 V 1 0 Minimum value
U2Max 0 - 2000000 V 1 106000 Maximum value
U2RepTyp Cyclic
Dead band
Int deadband
-
- Dead band Reporting type
U2LimHys 0.000 - 100.000 % 0.001 5.000 Hysteresis value in % of range and is
common for all limits
U2AngDbRepInt 1 - 300 Type 1 10 Cycl: Report interval (s), Db: In % of
range, Int Db: In %s
Table 368: VMSQI Non group settings (advanced)
Name
Values (Range) Unit Step Default Description
3U0ZeroDb 0 - 100000 m% 1 500 Zero point clamping
3U0HiHiLim 0 - 2000000 V 1 288000 High High limit (physical value)
3U0HiLim 0 - 2000000 V 1 258000 High limit (physical value)
3U0LowLim 0 - 2000000 V 1 213000 Low limit (physical value)
3U0LowLowLim 0 - 2000000 V 1 198000 Low Low limit (physical value)
U1ZeroDb 0 - 100000 m% 1 500 Zero point clamping
Table continues on next page
Section 14 1MRK 502 048-UEN A
Monitoring
486
Technical manual
