The above example also shows the five output signals, GRP1 to 4 for confirmation of
which group that is active, and the SETCHGD signal which is normally connected to
a SP16GGIO function block for external communication to higher level control
systems.
17.4 Test mode functionality TESTMODE
17.4.1 Identification
Function description IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Test mode functionality TESTMODE - -
17.4.2 Functionality
When the Test mode functionality TESTMODE is activated, all the functions in the
IED are automatically blocked. Activated TESTMODE is indicating by a flashing
yellow LED on the local HMI. It is then possible to unblock every function(s)
individually from the local HMI to perform required tests.
When leaving TESTMODE, all blockings are removed and the IED resumes normal
operation. However, if during TESTMODE operation, power is removed and later
restored, the IED will remain in TESTMODE with the same protection functions
blocked or unblocked as before the power was removed. All testing will be done with
actually set and configured values within the IED. No settings will be changed, thus
mistakes are avoided.
Forcing of binary output signals is only possible when the IED is in test mode.
17.4.3 Function block
TESTMODE
INPUT ACTIVE
OUTPUT
SETTING
NOEVENT
IEC09000219-1.vsd
IEC09000219 V1 EN
Figure 304: TESTMODE function block
17.4.4 Signals
Table 502: TESTMODE Input signals
Name
Type Default Description
INPUT BOOLEAN 0 Sets terminal in test mode when active
Section 17 1MRK 502 048-UEN A
Basic IED functions
632
Technical manual
