12.2.5.5 Settings
Table 225: QCBAY Non group settings (basic)
Name
Values (Range) Unit Step Default Description
AllPSTOValid Priority
No priority
- - Priority Priority of originators
12.2.6 Local remote LOCREM
12.2.6.1 Identification
Function description IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Local remote LOCREM - -
12.2.6.2 Functionality
The signals from the local HMI or from an external local/remote switch are applied via
the function blocks LOCREM and LOCREMCTRL to the Bay control QCBAY
function block. A parameter in function block LOCREM is set to choose if the switch
signals are coming from the local HMI or from an external hardware switch connected
via binary inputs.
12.2.6.3 Function block
LOCREM
CTRLOFF
LOCCTRL
REMCTRL
LHMICTRL
OFF
LOCAL
REMOTE
VALID
IEC09000076_1_en.vsd
IEC09000076 V1 EN
Figure 171: LOCREM function block
12.2.6.4 Signals
Table 226: LOCREM Input signals
Name
Type Default Description
CTRLOFF BOOLEAN 0 Disable control
LOCCTRL BOOLEAN 0 Local in control
REMCTRL BOOLEAN 0 Remote in control
LHMICTRL INTEGER 0 LHMI control
Section 12 1MRK 502 048-UEN A
Control
344
Technical manual
