D30 10
Screed lock, mechanical (O)
The screed locks must additionally be
engaged on both sides of the vehicle
prior to transportation with the screed
lifted.
Transportation with an unsecured screed
leads to a risk of accidents!
— Lift the screed.
— On both sides of the paver finisher,
slide the screed lock beneath the
crossbeams using the lever (1); place
the lever in the detent position.
ATTENTION!
Insert screed lock only at crown adjustment "zero"! Screed lock only for
transportation! Do not enter or work under screed only secured with screed lock for
transportation！
Danger of accidents!
