Towing
Heed all regulations and apply all safety measures applicable for towing heavy
construction machines.
The towing vehicle must be capable of securing the paver finisher, even on slopes.
Use only approved tow bars!
If necessary, remove any attachments and accessories from the paver finisher and
the screed until the basic width has been attained.
A hand pump (1) is located in the engine compartment (right side); it must be
actuated to be able to tow the machine.
Pressure for releasing the traction system brakes is built up with the hand pump.
- Release lock nut (2), screw threaded dowel (3) into pump as far as possible and
secure with lock nut.
- Actuate lever (4) of hand pump until
sufficient pressure has been built up
and traction system brakes have been
released.
On completion of the towing process,
restore the initial status.
Only release the traction system brakes
when the machine is sufficiently secured
against accidental rolling or is already
properly connected to the towing vehicle.
