E11 30
Extending the big ski
The big ski can be extended to both
the 9 m and 13 m versions.
Structure of the 9 m version:
Extension part at the front/rear each.
Structure of the 13 m version:
Two extension parts at the front/rear
each.
- Place the extension module (1) onto
the centre element (2) and secure
with a bolt (3).
