 To configure IP Groups:
1. Open the IP Group Table page (Configuration tab > VoIP menu > Control Network
submenu > IP Group Table).
2. Click the Add button: the following dialog box appears:
3. Configure the IP Group parameters according to the table below.
4. Click Submit.
5. To save the changes to flash memory, see 'Saving Configuration' on page 324.
Table 16-1: IP Group Parameters
Parameter Description
Common Parameters
Description
[IPGroup_Description]
Defines a brief description for the IP Group.
The valid value is a string of up to 29 characters. The default is
an empty field.
Proxy Set ID
[IPGroup_ProxySetId]
Assigns a Proxy Set ID to the IP Group. All INVITE messages
destined to this IP Group are sent to the IP address configured
for the Proxy Set.
Notes:
 Proxy Set ID 0 must not be used; this is the device's default
Proxy.
 To configure Proxy Sets, see 'Configuring Proxy Sets Table'
on page 178.
SIP Group Name
[IPGroup_SIPGroupName]
Defines the SIP Request-URI host name used in INVITE and
REGISTER messages sent to this IP Group, or the host name in
the From header of INVITE messages received from this IP
Group.
The valid value is a string of up to 49 characters. The default is
an empty field.
Note: If this parameter is not configured, the value of the global
parameter, ProxyName is used instead (see 'Configuring Proxy
and Registration Parameters' on page 186).
Contact User
[IPGroup_ContactUser]
Defines the user part of the From, To, and Contact headers of
SIP REGISTER messages, and the user part of the Contact
To Next Page
