32.7
Removing and installing handlebar
•
Remove left/right handlebar fittings.
•
Remove handlebar.
•
Install in the reverse order of work.
•
Install the lower clamp block with the arrow
pointing forwards.
•
Tighten the front clamp block first.
L Note:
The clamp is higher at the front.
e Caution:
Ensure that brake hoses are correctly located.
X Tightening torque:
Clamp to fork bridge .................................... 21 Nm
Handlebar adjusting dimension:
Standard/Police
Distance from turn indicator switch to fuel tank with
handlebar at full left or right lock
....................... variable, 30...50 mm (1.18...1.97 in)
Optional extra/Easy Rider
Distance from turn indicator switch to fuel tank with
handlebar at full left or right lock
...................................................... 30 mm (1.18 in)
CUB0010
