34.5
Removing and installing front brake
caliper
•
Drain fluid from brake system.
•
Detach brake line (1).
e Caution:
Do not allow brake fluid to come into contact with
painted parts of the motorcycle, because brake fluid
destroys paint.
•
Unscrew the brake caliper.
•
Force back the brake pads/pistons (arrows).
•
Carefully remove the brake caliper.
e Caution:
Do not damage brake pads.
•
Install by following the above work instructions in
the reverse order.
•
Force back the brake pads/pistons.
•
Fill/bleed the brake system.
e Caution:
Use new sealing rings (2).
Do not damage brake pads.
X Tightening torque:
Brake caliper at fork slider tube.................... 40 Nm
Brake hose to brake caliper ......................... 15 Nm
Bleed screw at brake caliper ......................... 7 Nm
RS340021
2
1
RS340050
