33.18
Installing rear wheel drive
•
Coat splines at sliding element (arrow) with
Staburags NBU 30 PTM.
•
Offer up the rear wheel drive assembly and guide
the sliding element into the drive shaft.
X Tightening torque:
Rear wheel drive to swinging arm................ 21 Nm
•
If necessary, fill with oil.
Fill quantity:
(up to lower edge of thread on oil filler plug)
Initial
filling ...........app. 0.20 l (0.35 Imp. pint/0.21 US quart)
During oil
changes .....app. 0.18 l (0.32 Imp. pint/0.19 US quart)
Oil grade:
Brand-name hypoid gear oil, SAE 90, API class GL 5
•
[ABS] Install the brake disc in the previously
marked position.
•
Install the rear wheel.
•
Install brake caliper
e Caution:
Do not damage brake pads; do not tilt when install-
ing.
•
Install speedometer signal transmitter.
•
[ABS] Install sensor.
•
[ABS] Check that sensor gap is correct.
ABS rear
sensor gap: ........ 0.50...0.55 mm (0.019...0.021 in)
C330011
