34.7
Removing and installing rear brake
caliper
•
Drain fluid from brake system.
e Caution:
Do not allow brake fluid to come into contact with
painted parts of the motorcycle, because brake fluid
destroys paint.
•
Detach the brake line from the brake caliper.
•
Unscrew the brake caliper.
•
Install by following the above work instructions in
the reverse order.
•
Force back the brake pads/pistons.
•
Fill/bleed the brake system.
•
To bleed, release the brake caliper and position
it with the bleed nipple at the highest point.
e Caution:
Renew sealing rings for brake line.
Do not damage brake pads.
X Tightening torque:
Brake caliper to rear wheel drive .................. 40 Nm
Brake hose to brake caliper ......................... 15 Nm
Bleed screw at brake caliper.......................... 4 Nm
C330012
