33.5
Removing, dismantling,
reassembling and installing rear
wheel drive
Removing rear wheel drive
•
Raise the motorcycle with the auxiliary stand,
BMW No. 00 1 550.
•
Drain the oil.
•
Detach the brake caliper and secure it to the rear
frame with a cable strap.
•
Remove sensor (1) for the speedometer signal.
•
Remove ABS sensor (2).
•
Remove rear wheel.
•
Heat the brake disc retaining screws to 120 °C
(248 °F).
L Note:
Mark the position of the brake disc.
The sensor gap setting remains unchanged.
•
Detach the rear wheel drive and pull it off the
drive shaft.
Removing input bevel pinion
•
Press out splined section of shaft.
•
If necessary, remove/install circlip.
C330011
h
120
2
1
C330090
