34.10
Removing/installing rear brake disc
•
Remove rear wheel.
•
Remove the brake caliper.
•
Heat the brake disc retaining screws to 120 °C
(248 °F) and remove them.
L Note:
Mark the position of the brake disc.
The sensor gap setting remains unchanged.
•
Install by following the above work instructions in
the reverse order.
•
Degrease the brake disc before installing.
e Caution:
[ABS] Check sensor gap and adjust with spacing
plates if necessary.
[ABS] If the brake disc and therefore the sensor
wheel are renewed, the disc’s lateral runout must be
determined/marked.
Sensor gap:............ 0.45...0.55 mm (1.77...2.22 in)
X Tightening torque:
Brake disc to rear wheel drive
(clean thread + Loctite 273).......................... 21 Nm
C330013
