36.5
Removing and installing front wheel
Removing front wheel
•
Place the motorcycle on the auxiliary stand,
BMW No. 00 1 550.
•
Remove brake calipers.
L Note:
Do not apply handbrake lever with brake calipers re-
moved/front wheel removed.
•
Remove retaining screw (1).
•
Loosen clamping screws (2).
•
Remove quick-release axle.
•
Take out spacing bushing (3/4) and front wheel.
Installing front wheel
•
Install front wheel and spacing bushings.
•
Apply a light coating of Molykote paste to the
quick-release axle/install it.
•
Tighten the retaining screw (1).
•
Install the brake calipers.
•
Compress the front fork firmly several times.
•
Tighten the clamp screws (2).
•
[ABS] Check sensor gap and adjust if necessary.
ABS sensor gap:.... 0.45...0.55 mm (1.77...2.22 in)
X Tightening torque:
Quick-release axle threaded connection ...... 30 Nm
Quick-release axle clamp screws................. 20 Nm
Brake caliper at fork slider tube.................... 40 Nm
4
C360020
1
2
3
