DIRECTION 5854713-100, REVISION 2
VENUE FIT™ SERVICE MANUAL
Chapter 5 - Components and Function (Theory) 5-3
PRELIMINARY
The Venue Fit™scanner supports the following RS probes:
• Regular RS Probes with up to 128 channels
• Regular RS Probes with Internal Mux
• TEE RS Probes with Temperature sensing (6Tc-RS)
• RS probes with Haystack Needle tracking
• RS probes with control buttons
NOTE: For a detailed description of Venue Fit™ system operating modes, refer to the Venue Fit™ User
Manual.
The Venue Fit™ ultrasound scanner technology is based on software beam-forming.
Signals flow from the M-PSB through the Front End Board (C-FEB) Electronics to the Back End Board
(M-BEB), and finally displayed on the touch display.
5-2-2-1 System Configuration and Software
System configuration is stored on the internal SSD attached to the Back End Unit.
At power up, all necessary software is loaded from the M-BEB SSD.
5-2-2-2 Electronics
The Venue Fit™ system internal electronics are divided into three:
• Compact Front End Board (C-FEB)
• Back End
• Venue Fit™ Display
The interconnections within the Front End (C-FEB) and the Back End (M-BEB) is via two stacked
connectors (one for power supply and the other one for control and data signals). The touch display
module is connected via eDP interface to the Back End and additional cable is connected to the Front
End (interface for power management controller - signals for On/Off and indicators).
