DIRECTION 5854713-100, REVISION 2
VENUE FIT™ SERVICE MANUAL
3-10 Chapter 3 - System Setup
PRELIMINARY
3-3-5 Physical Inspection
3-3-5-1 System Voltage Settings
3-3-6 EMI Protection
The Venue Fit™ Ultrasound Unit has been designed to minimize the effects of Electro Magnetic
Interference (EMI). Many of the covers, shields, and screws are provided primarily to protect the system
from image artifacts caused by this interference. For this reason, it is imperative that all covers and
hardware are installed and secured before the unit is put into operation.
CONNECTING A VENUE FIT™ SCANNER TO INCORRECT VOLTAGE LEVEL WILL
MOST LIKELY DESTROY IT.
CONNECT THE SYSTEM ONLY IN ACCORDANCE WITH THE VOLTAGE INDICATED ON
THE PRODUCT LABEL.
