DIRECTION 5854713-100, REVISION 2
VENUE FIT™ SERVICE MANUAL
Chapter 3 - System Setup 3-11
PRELIMINARY
Section 3-4
Preparing for Setup
3-4-1 Verifying Customer Order
Compare items received by the customer to that which is listed on the delivery order. Report any items
that are missing, back ordered, or damaged.
3-4-2 Physical Inspection
Verify that the Venue Fit™ arrived intact (visual inspection).
If the Venue Fit™ has been damaged, please refer to DAMAGE IN TRANSPORTATION on page x in
the beginning of this manual.
3-4-3 Component Inspection
After verifying that all the required parts are included in the shipping crate, inspect the system components
using the checklist supplied below. In addition, ensure that all the labels described in Chapter 1 -
Introduction are present, accurate and in good condition, and enter the serial number printed on the main
label into the system installation details card, as described in Paperwork After Setup on page 3-53.
3-4-3-1 Damage Inspection Checklist
Visually inspect the contents of the shipping carton for damage. If any parts are damaged or missing,
contact an authorized GE Service Representative.
A Damage Inspection Checklist for the Venue Fit™ portable ultrasound scanner is provided in Tab le 3 -
11 below.
Table 3-11 Damage Inspection Checklist - Venue Fit™ Systems
Step Item Recommended Procedure
1
Venue Fit™
System
Verify that the system is switched OFF and unplugged. Clean the system. Check
that there are no dents or scratches and that no internal parts are exposed.
2
Probes
Check all probes for wear and tear on the lens, cable, and connector. Look for bent
or damaged pins on the connector and in the connector socket on the unit. Verify
that the EMI fingers around the probe connector socket housing are intact. Check
the probe locking mechanism and probe switch.
3
Rear Panel
Check the rear panel connectors for bent pins, loose connections and loose or
missing hardware. Screw all the cable connectors tightly to the connector sockets
on the panel. Verify that the labeling is in good condition.
4
Power Cord/s
Check the power cord for cuts, loose hardware, tire marks, exposed insulation, or
any deterioration. Verify continuity.
5
Venue Fit™ Cart Check that there are no dents or scratches and that no internal parts are exposed.
6
Peripherals
Check and clean the peripherals in accordance with the manufacturer’s directions.
To prevent EMI or system overheating.
