DIRECTION 5854713-100, REVISION 2
VENUE FIT™ SERVICE MANUAL
Chapter 7 - Diagnostics/Troubleshooting 7-13
PRELIMINARY
7-4-4-3 Connected Probes
Connected Probes shows probes connected to the system.
Note: The information on Connected Probes is available to all service class licenses.
Figure 7-14 Connected Probes
The following table lists all the elements available on Connected Probes section:
7-4-4-4 Gather Logs
Gather Logs provides a way to collect system logs and place the log files in the D:\Service directory for
retrieval by the online center. Log files are compressed into a zip file and the file path and name display.
Note: The Gather Logs is available to all service class licenses.
To access the Gather Logs utility:
1.) Tap Utility on the top bar and select Gather Logs
2.) Select one of the following:
• 1 Day Logs
• 1 Week Logs
• All Logs
Table 7-29 Connected Probes
Element DESCRIPTION
Active Probe Tempera-
ture (Celsius)
When available, temperature of the active probe.
Relevant for TEE probe.
Probe Name Name of the probe connected to the system
Probe ID Identifier of the probe connected to the system.
Serial Number Serial number of the probe connected to the system. If the serial number of
the probe is not available, then N/A will be displayed.
Status Statuses of the probe connected to the system. Valid values are:
• Active
• Non Active
To Next Page
