DIRECTION 5854713-100, REVISION 2 VENUE FIT™ SERVICE MANUAL
8-56 Chapter 8 - Replacement Procedures
PRELIMINARY
8-4-3 Required Functional Checks per Replacement Part Category
Tab l e 8-3 6 lists the Functional Checks to be performed after each type of Replacement Procedure.
Part Number Replacement Element and Procedure Functional Checks Required
System Parts
S5764348 Battery
• 4-3-7-1 -Battery Charging Test
• 7-3-2 -Running System Diagnostics
S5825567 Battery Cover assy – CRU - Venue Fit • N/A
S5775296 Rear Cover Assy – FRU - Venue Fit
• 7-3-2 -Running System Diagnostics
• 4-3-3 -Image Quality Tests
• 4-3-6 -Mechanical Functions Checks
S5845282 kIckstand Assy - FRU - Venue Fit
• Verify that the system is stable when place on a flat table.
S5823647 MPSB – FRU - Venue Fit
• 7-3-2 -Running System Diagnostics
• 4-3-3 -Image Quality Tests
S5823646 MPSB Levers – FRU - Venue Fit
• 7-3-2 -Running System Diagnostics
• 4-3-3 -Image Quality Tests
S5823650 C-FEB FRU - Venue Fit
• 7-3-2 -Running System Diagnostics
• 4-3-3 -Image Quality Tests
S5825563 Touch Display – FRU - Venue Fit
• Visual inspection
• Verify proper Touch functionality by operating the system:
changing gain, depth, entering configuration menus, pinch
gesture.
S5819355
MBEB – FRU - Venue Fit
• Boot to application
• 7-3-2 -Running System Diagnostics
• 4-3-3 -Image Quality Tests
•
S5841204
MBEB Magram – FRU - Venue Fit
• Boot to application
• 7-3-2 -Running System Diagnostics
• 4-3-3 -Image Quality Tests
•
S5845043 SSD FRU - Venue Fit
• Visual inspection
• 7-3-2 -Running System Diagnostics
• 4-3-3 -Image Quality Tests
S5826571
Speakers Assy – FRU - Venue Fit
• 7-3-2 -Running System Diagnostics
• 4-3-3 -Image Quality Tests
•
S5789349 Venue Fit Fan FRU - Venue Fit
• Visual inspection
• 7-3-2 -Running System Diagnostics
• 4-3-3 -Image Quality Tests
•
Cart Parts
Table 8-36 Replacement Procedures - Required Functional Checks
