VENUE FIT™ SERVICE MANUAL
Chapter 10 - Care and Maintenance 10-5
PRELIMINARY
Section 10-4
Tools Required
10-4-1 Tools Required for Servicing the Venue Fit™
The following tools (TORX bits or drivers) are needed to service the ultrasound scanner. .
Table 10-3 Tools Used for Servicing the Venue Fit™
Item No. Tool Size Torque Comments
1.
Bit # TX-10
M2.5
• 90 degree “L“ are suggested.
• A full set of 90 degree “L“ TORX wrenches are recommended.
2.
Bit # TX-15
M3
3.
Bit # TX-20
M4
4.
Bit # TX-25
M5
5.
Bit # TX-30
M6
6.
Bit # TX-45
M10
7.
Socket Set
(must include 7mm socket)
8.
Side cutter (diagonal)
5 or 6 inch
9.
Flat Blade Driver
3.2 mm
10.
Flat Blade Driver
4 mm
11.
Flat Blade Driver
6 mm
12.
Phillips Driver
PH1
13.
Phillips Driver
PH2
14.
Phillips Driver
PH3
15.
Hex Key
1.5 mm
(Unbrako Key / Allen Key)
16.
Hex Key
2 mm
(Unbrako Key / Allen Key)
17.
Hex Key
2.5 mm
(Unbrako Key / Allen Key)
18.
Hex Key
3 mm
(Unbrako Key / Allen Key)
19.
Hex Key
4 mm
(Unbrako Key / Allen Key)
20.
Hex Key
5 mm
(Unbrako Key / Allen Key)
21.
Hex Key
6 mm
(Unbrako Key / Allen Key)
22.
Hex Key
8 mm
(Unbrako Key / Allen Key)
23.
Hex Key
10 mm
(Unbrako Key / Allen Key)
24.
Hex Key
M12
Rear Casters: 130 Nm (Unbrako Key / Allen Key)
25.
Nut Driver
5 mm
26.
Nut Driver
3/16 inch
