GE Versana Balance User Manual

Functional checks
Versana Balance – Basic Service Manual System view 4-57
5808768-100 English Rev.9
4-4-8 M Mode Checks
4-4-8-1 Preparations
• Connect one of the probes to the scanner’s left-most probe
connector.
• Turn ON the scanner.
The 2D Mode window is displayed (default mode).
• Press M Mode on the Operator panel to bring up an
M-Mode picture on the screen.
Use the trackball to position the cursor over the required
area of the image.
4-4-8-2 Adjust the M Mode controls
These Image Controls are used to optimize the M mode picture.
Verify that all the listed controls are working as intended:
• Adjust Horizontal sweep to optimize the display resolution.
Adjust Gain and TGC controls to adjust the range to be
imaged.
Adjust Compression and Edge Enhance to further
optimize the display.
Adjust Rejection to reduce noise while taking care not to
eliminate significant low-level diagnostic information.

GE Versana Balance Specifications

General

Category	Ultrasound System
Doppler Modes	Color Doppler, Power Doppler, Pulsed Wave Doppler, Continuous Wave Doppler
Power Requirements	100-240 V AC, 50/60 Hz
DICOM Compatibility	Yes
Wireless Connectivity	Optional
Display	LED
Transducers	convex, linear, phased array
Image Storage	USB
Connectivity	USB, HDMI, Ethernet, DICOM
Applications	Obstetrics, Gynecology, Cardiology, Vascular, Urology
Imaging Modes	2D, M-Mode, 3D/4D
Operating Temperature	10°C to 40°C
Storage Temperature	-20°C to +60°C
Humidity Range	20% to 80% (non-condensing)
Display Size	15.6 inches
Transducer Ports	3 active transducer ports
