GE Versana Balance User Manual

Functional checks
Versana Balance – Basic Service Manual System view 4-61
5808768-100 English Rev.9
4-4-10 PW Doppler Mode Checks
4-4-10-1 Introduction
PW Doppler are used to measure velocity (most often in blood).
Doppler mode can be done with a special pencil probe or with
an ordinary probe. By using an ordinary probe, you can first
bring up a 2D picture for navigation purpose and then add PW
Doppler.
4-4-10-2 Preparations
• Connect one of the probes to the scanner.
• See
4-4-13 ‘Probe/Connectors Check’ on page 4-66 for info
about connecting the probes.
For available probes, see 9-3-2 ‘Probe’ on page 9-6:
• Turn ON the scanner
The 2D Mode window is displayed (default mode).
• If needed, adjust the Display’s Brightness and Contrast
setting.
Press PW to start Pulsed Wave Doppler (PW).
Use the trackball to select the Area of Interest (Sample
Volume) in PW.

GE Versana Balance Specifications

General

Category	Ultrasound System
Doppler Modes	Color Doppler, Power Doppler, Pulsed Wave Doppler, Continuous Wave Doppler
Power Requirements	100-240 V AC, 50/60 Hz
DICOM Compatibility	Yes
Wireless Connectivity	Optional
Display	LED
Transducers	convex, linear, phased array
Image Storage	USB
Connectivity	USB, HDMI, Ethernet, DICOM
Applications	Obstetrics, Gynecology, Cardiology, Vascular, Urology
Imaging Modes	2D, M-Mode, 3D/4D
Operating Temperature	10°C to 40°C
Storage Temperature	-20°C to +60°C
Humidity Range	20% to 80% (non-condensing)
Display Size	15.6 inches
Transducer Ports	3 active transducer ports
