GE Versana Balance User Manual

General Procedures and Functional Checks
4-68 System view Versana Balance – Basic Service Manual
5808768-100 English Rev.9
4-4-14 ECG Check
4-4-14-1 Introduction
The ECG capability on this unit, is intended as use as a trigger
for measurements, but can also be viewed on the screen.
4-4-14-2 Parts needed
• ECG Module
4-4-14-3 Preparations
None
4-4-14-4 ECG Check
Table 4-2: ECG Checks
Step Task Expected Result(s)
1 Connect the ECG harness to the connector
under the control panel.
The unit displays a straight curve along the
bottom edge of the image sector on the screen.
2 Connect the three leads to an ECG simulator,
or
Fasten the three ECG Pads to your body and
connect the three leads to respective ECG
Pad.
When connecting, the signal on the screen will
be noisy.
When the connection is completed, a typical
clean ECG signal is displayed.

GE Versana Balance Specifications

General

Category	Ultrasound System
Doppler Modes	Color Doppler, Power Doppler, Pulsed Wave Doppler, Continuous Wave Doppler
Power Requirements	100-240 V AC, 50/60 Hz
DICOM Compatibility	Yes
Wireless Connectivity	Optional
Display	LED
Transducers	convex, linear, phased array
Image Storage	USB
Connectivity	USB, HDMI, Ethernet, DICOM
Applications	Obstetrics, Gynecology, Cardiology, Vascular, Urology
Imaging Modes	2D, M-Mode, 3D/4D
Operating Temperature	10°C to 40°C
Storage Temperature	-20°C to +60°C
Humidity Range	20% to 80% (non-condensing)
Display Size	15.6 inches
Transducer Ports	3 active transducer ports
