GE Versana Balance User Manual

Manual Overview
Versana Balance – Basic Service Manual System view 1-3
5808768-100 English Rev.9
1-2 Manual Overview
This manual provides installation and service information for the
Versana Balance Ultrasound system. It is divided in ten chapters
as shown below.
1-2-1 Contents in this manual
The manual is divided into ten chapters.
In the beginning of the manual, before chapter 1, you will find
the Revision overview, the Important precautions including
Translation policy, Damage in transportation, Certified electrical
contractor statement, Omission & errors, Service safety
considerations and Legal notes, and the Table of Contents
(TOC).
An Index has been included after Chapter 10.
Table 1-1: Contents in this manual
Chapter
number
Chapter title Description
1.
Introduction Contains a content summary and warnings.
2.
Site preparations Contains pre-setup requirements for the Versana
Balance.
3.
System Setup Contains setup procedure with procedure
checklist for the system.
4.
General Procedures
and Functional
Checks
Contains functional checks that must be
performed as part of the installation, or as
required during servicing and periodic
maintenance.
5.
Components and
Functions (Theory)
Contains block diagrams and functional
explanations of the electronics.
6.
Service Adjustments Contains instructions on how to make any
available adjustments to the Versana Balance.

GE Versana Balance Specifications

General

Category	Ultrasound System
Doppler Modes	Color Doppler, Power Doppler, Pulsed Wave Doppler, Continuous Wave Doppler
Power Requirements	100-240 V AC, 50/60 Hz
DICOM Compatibility	Yes
Wireless Connectivity	Optional
Display	LED
Transducers	convex, linear, phased array
Image Storage	USB
Connectivity	USB, HDMI, Ethernet, DICOM
Applications	Obstetrics, Gynecology, Cardiology, Vascular, Urology
Imaging Modes	2D, M-Mode, 3D/4D
Operating Temperature	10°C to 40°C
Storage Temperature	-20°C to +60°C
Humidity Range	20% to 80% (non-condensing)
Display Size	15.6 inches
Transducer Ports	3 active transducer ports
