Replacement Procedures

8-6 System view Versana Balance – Basic Service Manual

5808768-100 English Rev.9

8-3-2 Tools needed for servicing Versana Balance

NOTE: Please use the correct Screwdrivers listed in Table 8-1.

Table 8-1: Standard tools list for Versana Balance

Part

Name

Part No. QTY Screw Description Screwdriver Description

1 screw 2327766 4 D2 SCREW M3X5

NYLOK

Common Phillips Screwdriver

2 screw 2327793 100 Screw-M3X8 Common Phillips Screwdriver

3 screw 5477579 4 DScrew_DIN 912 M6_20 Common Phillips Screwdriver

4 screw 5477414 8 Screw DIN 965A M4x10 Common Phillips Screwdriver

5 screw 5439265 51 Screw-M4X10 Common Phillips Screwdriver

6 screw 5495588 3 Screw M3X6 CSK Common Phillips Screwdriver

7 screw 5138465 3 Screw FH M2.5X5-NL Common Phillips Screwdriver

8 screw 5495588 7 Screw M3X6 CSK Common Phillips Screwdriver

9 screw 5477414 5 Screw DIN 965A M4X10 Common Phillips Screwdriver

10 screw 2327785 3 D2 SCREW

M2X4,NYLOK

Common Phillips Screwdriver

11 screw 5478161 48 Taping SCREW M3X6 Common Phillips Screwdriver

12 screw 5490719 4 PM_SW 4X8 Screw Common Phillips Screwdriver

13 screw 1041-M10

C010-37

2 Magna M10 screw Common Phillips Screwdriver

14 screw 5495592 7 Captive SCREW M4X16 Common Phillips Screwdriver

GE Versana Balance Specifications

General

Category	Ultrasound System
Doppler Modes	Color Doppler, Power Doppler, Pulsed Wave Doppler, Continuous Wave Doppler
Power Requirements	100-240 V AC, 50/60 Hz
DICOM Compatibility	Yes
Wireless Connectivity	Optional
Display	LED
Transducers	convex, linear, phased array
Image Storage	USB
Connectivity	USB, HDMI, Ethernet, DICOM
Applications	Obstetrics, Gynecology, Cardiology, Vascular, Urology
Imaging Modes	2D, M-Mode, 3D/4D
Operating Temperature	10°C to 40°C
Storage Temperature	-20°C to +60°C
Humidity Range	20% to 80% (non-condensing)
Display Size	15.6 inches
Transducer Ports	3 active transducer ports
