General Procedures and Functional Checks
4-70 System view Versana Balance – Basic Service Manual
5808768-100 English Rev.9
4-4-16 Back End Processor checks
• If all the previous tests have been passed successfully, the
Back End Processor is most likely OK.
If the system seems to be operating erratically, please refer
to
‘Diagnostics/Troubleshooting’ on page 7-1.
4-4-17 Operator Panel Test
• The Operator Panel is tested when the Versana Balance is
powered up as part of the start-up scripts, run at every
start-up.
For more info, please refer to
‘Diagnostics/Troubleshooting’
on page 7-1.
4-4-18 Peripheral checks
Check that peripherals work as described below:
4-4-18-1 Printer checks
The internal printer is controlled from the Print and Store keys
on the Versana Balance’s Operator Panel.
The factory default is:
• Print for the standard printer
Store for the screen capture to clipboard
4-4-19 Turn OFF Power to Versana Balance
See 4-2-3 ‘Power off’ on page 4-8 for more information.
Table 4-3: Peripheral Checks
Step Task to do Expected Result(s)
1. Press FREEZE Stop image acquisition.
2. Press PRINT on the Control Panel The image displayed on the screen is printed on B&W printer.
3. Connect with Foot Switch on USB
port and press once.
To start image acquisition (the same function as FREEZE
key).

GE Versana Balance Specifications

General

Category	Ultrasound System
Doppler Modes	Color Doppler, Power Doppler, Pulsed Wave Doppler, Continuous Wave Doppler
Power Requirements	100-240 V AC, 50/60 Hz
DICOM Compatibility	Yes
Wireless Connectivity	Optional
Display	LED
Transducers	convex, linear, phased array
Image Storage	USB
Connectivity	USB, HDMI, Ethernet, DICOM
Applications	Obstetrics, Gynecology, Cardiology, Vascular, Urology
Imaging Modes	2D, M-Mode, 3D/4D
Operating Temperature	10°C to 40°C
Storage Temperature	-20°C to +60°C
Humidity Range	20% to 80% (non-condensing)
Display Size	15.6 inches
Transducer Ports	3 active transducer ports
