134 43-TV-25-30 Iss.6 GLO Aug 07 UK
Figure 4.2 Password Network Synchronisation setup
If Master is selected a keypad will be displayed to
enter the new password group name.
If Slave is selected a list of existing password
groups will be displayed
This screen is available for a Master
recorder so associated slaves can
be added to its password group.
Only recorders with Pwd NetSync
enabled will be displayed here.
Recorders in red do not belong to
any password group and are availa-
ble to be added to a group.
Touch the screen to select from the
available recorders shown in red.
Recorders that are enabled for
password net sync, and that already
belong to this password group, will
be displayed in green.
