43-TV-25-30 Iss.6 GLO Aug 07 UK 17
Analogue Input Channel Numbers
Analogue Input cards are either 4, 6 or 8 channels with a full length connector taking up 8
channels even if only 4 or 6 are operational.
Analogue Input Connection Details
Current Input
For Current (mA) Input fit a 10
resistor across the + and - pins of the 12-way mating half
analogue connector. Figure 2.7 on page 19 shows a 10
(±0.1%) resistor fitted to chan-
nel 5 for a current (mA) input.
Table 2.2 :
Minitrend QX and Multitrend SX Analogue Input card
Card Position
Slot A Slot B Slot C Slot D Slot E Slot F
Channel number 1 to 8 9 to 16 17 to 24 25 to 32 33 to 40 41 to 48
Table 2.3 :
eZtrend QXe Analogue Input cards
Card 3 CH. 6 CH. 9 CH. 12 CH.
A 1-3 1-6 1-3 1-6
B 9-14 9-14
WARNING
HAZARDOUS VOLTAGES
Insulation from channel to channel: Normally a channel can be safely connected to a
hazardous voltage up to 300V AC common mode* with respect to earth. However,
where a channel is connected to a safety low voltage circuit, an immediately adjacent
channel must be adequately insulated from hazardous voltages between 150V AC
and 300V AC max. This insulation should comprise of at least 1.5mm air gap, or a bar-
rier rated greater than 1400V AC. This is to ensure that protection of the safety low
voltage circuit is fully maintained.
*Common Mode voltage is a voltage applied between the whole channel and earth,
not between pins on a channel. 300V AC is permitted at Measurement Category CAT
ll (Overvoltage Category ll)
Failure to comply with these instructions could result in death or serious injury.
NOTICE
For 12 and 24-way connectors; torque setting 0.4 Nm/3.5lbf-in. Do not over tighten.
Recommended wire size for termination connector is 22-12 AWG (American Wire
gauge) equivalent to 22-14 SWG (Standard Wire Gauge). AWG metric 0.6426-
2.052mm in diameter or SWG metric 0.71 - 2.03mm in diameter.
To Next Page
