208 43-TV-25-30 Iss.6 GLO Aug 07 UK
Getting connected - IP Address
Stand alone system
This is for connecting a local device direct to a PC using an Ethernet crossover cable. By
using a crossover cable, the PC is able to receive data transmitted from the device.
Contact your IT systems administrator for setting up this link.
The TCP/IP properties are displayed showing the PC’s IP address and the Subnet mask.
Make a note of the IP Address and the Subnet mask. If there is no IP address or Subnet
mask displayed, contact your IT systems administrator.
When this information is entered, the next stage is to configure the device.
See “TCP/IP” on page 73.
Switch/hub
Uplink (optional) to
other networks
Mains
Mains
Figure 8.1 Stand Alone system
