Item
1
Description of Items in Figure 4-20
Pulse repetition interval (PRI) of signal
I.
PRI is measured in time units. PRI is equivalent to
l/PRF,
where
PRF is the pulse repetition frequency.
2
Pulse repetition interval (PRI) of signal 2.
3
Pulse width (7) of signal
1.
Pulse width is also referred to as
7
(tau).
4
Pulse width
(T)
of signal 2.
5
Signal delay of signal 2. Notice that the signal delay is zero for signal
1.
6
Gate trigger input for Option 105. The trigger input coincides with signal
1.
Figure 4-20.
Pulse Repetition Interval and Pulse Width
(with Two Signals Present)
Making Measurements 4-25
