100 MHz COMB OUT supplies a 100 MHz reference signal that has harmonics up to
22 GHz. Fbr the HP 85921, HP 8593E, or HP 8596E only.
17 Memory card reader reads from or writes to a memory card. The memory card reader is
standard with an HP 85913, HP 85933, HP 85943, HP 85953, and HP 85963. It is also
available for the HP 859OL, HP 8592L, and HP 8594L as Option 003.
18 RF OUT 5OD supplies a source output for the built-in tracking generator.
Fbr Option 010 only. See liable 2-l.
Caution
If the tracking generator output power is too high, it may damage the device
under test. Do not exceed the maximum power that the device under test can
tolerate.
RF OUT 750 supplies a source output for the built-in tracking generator.
For Option 011 only. See lbble 2-l.
‘able 2-l. RF Output Frequency Range
Model Number
HP 8590L 100 kHz to 1.8 GHz
HP 85913
100 kHz to 1.8 GHz
HP 85933 9 kHz to 2.9 GHz
HP 85943 9 kHz to 2.9 GHz
HP 85953 9 kHz to 2.9 GHz
HP 85963 9 kHz to 2.9 GHz
Option 010
Frequency Range
Option 011
Frequency Range
1 MHz to 1.8 GHz
1 MHz to 1.8 GHz
not available
not available
not available
not available
19 ILINE) turns the instrument on and off. The symbols to the left of the line switch
represent the up position of the switch when the instrument is off, and the down
position of the switch when the instrument is on. An instrument self-check is performed
every time the instrument is turned on. After applying power, allow the temperature of
the instrument to stabilize for best measurement results.
Note
The instrument continues to draw power when it is plugged into the ac power
source even if the line power switch is off.
2-4 Getting Started
