To Save a Trace
Saving trace data is very similar to saving state data. Saving trace data saves both the trace
data and the state data.
1. Enter a screen title, if desired, by using
(j-1
and Change Title .
2. Set up the trace to be stored.
3.
Press
ISAVE).
If CARD is underlined, press INTERNAL CARD to select INTERNAL.
4-
Press Trace
-+
Intrnl . This accesses a menu displaying TRACE A , TRACE B , and
TRACE C.
5.
Press the
softkey
for the trace that you want to save: TRACE A , TRACE B , or TRACE C .
REGISTER
#
and MAX REG
#
= are displayed on the spectrum analyzer display. The number
after MAX REG # = indicates the maximum register number that can be entered for trace
storage in spectrum analyzer memory.
6. Use the numeric keypad to enter a number from 0 to the maximum register number and
then press
(m).
To Recall a Trace
l.
Press
(m).
If CARD is underlined, press INTERNAL CARD to select INTERNAL.
2.
Press Internal
+
Trace.
This accesses a menu displaying TRACE A , TRACE B , TRACE C ,
LIMIT LINES , and AMP COR .
3.
Press TRACE A , TRACE B , or TRACE C to select the trace in which you want to place the
trace data.
4. Enter the register number under which the trace was stored.
5. Press (ENTER). The recalled trace is placed in the view mode and the spectrum analyzer state
is changed to the state that was saved.
Trace data can also be recalled by using the catalog:
1.
Press
(KKKiJ.
If CARD is underlined, press INTERNAL CARD to select INTERNAL.
2.
Press Catalog Internal ,
CATALOG REGISTER. Use the knob to highlight the number
of the trace register to be retrieved. The trace registers have a “TR” preceding the trace
register number.
3.
Press LOAD FILE. The recalled trace is placed into trace B and the spectrum analyzer state
is changed to the state that was saved.
Using Analyzer Features 5-7
