HP 8590 E-Series User Manual

Service Functions
Two types of functions are available for service use only:
w Service calibration functions.
n Service diagnostic functions.
These service functions are designed for service use only. However, brief descriptions for each
function are provided in this chapter. For more detailed descriptions and information about the
use of each function, refer to the Service Guide for your instrument.
Service documentation can be obtained by ordering Option 915 through your HP Sales
and Service office. Option 915 is described in more detail under Chapter 10 “Measurement
Personalities, Options, and Accessories” in this manual.
Service Calibration Functions
Service Cal accesses the following service calibration softkeys:
CAL MXR
(HP 8592L, HP 85933, HP 85953, or HP 85963 only)
CAL TIMEBASE
EDIT FLATNESS
EXECUTE TITLE
EXIT
Flatness Data
IDNUM
INIT FLT
SET ATTN ERROR
STOR PWR ON UNITS
Service Diagnostic Functions
Service Diag accesses the following diagnostic softkeys:
c,f~ LOCK ON OFF
+lOV REF DETECTOR
-lOV REF DETECTOR
2v REF DETECTOR
ALC TEST
(HP 8590L or HP 85913 with Option 010 or 011 only)
ANALYZER GAINS
AUXB
(HP 8590L or HP 85913 only)
BINARY SPAN
(HP 8590L or HP 8591E only)
COARSE TUNE DAC
DACS
DISPLAY CAL DATA
DROOP
FINE TUNE DAC
FM COIL DRIVE
FM GAIN
(Option 102 or 103 only)
