HP 8590 E-Series User Manual

AM/FM Demodulator with Speaker and TV Sync Trigger Circuitry
(Option 102)
Ftw HP 85913, HP 8593E, HP 8594E, HP 8595E, and HP 85963 only. Option 102 enables you
to use amplitude or frequency demodulation and to listen to a demodulated signal. Option
102 also allows you to TV trigger on the selected line of a TV video picture frame if both
Option 101 and 102 are installed. The sweep triggering works with interlaced or noninterlaced
displays for the NTSC, PAL, and SECAM formats. Also see Option 301 below.
Option 102 is also available as a retrofit kit (Option R02) after the purchase of your spectrum
analyzer, or as a kit HP part number 5062-6457.
Quasi-Peak Detector and AM/FM Demodulator With Speaker (Option 103)
Fbr HP 8591E, HP 8593E, HP 8594E, HP 85953, and HP 8596E only. Option 103 enables you to
make automatic or manual quasi-peak measurements, to listen to a demodulated signal, and to
use amplitude or frequency demodulation.
Option 103 is available as a kit, order HP 11946A.
Time-Gated Spectrum Analysis (Option 105)
Fbr HP 8591E, HP 85933, HP 8594E, HP 8595E, and HP 8596E only. Option 105 allows you to
selectively measure the spectrum of signals that may overlap in the frequency domain, but
be separated in the time domain. By adjusting a time gate based on a user-supplied trigger
signal, you can significantly increase the diagnostic capability of your spectrum analyzer for
time-interleaved signals.
Option 105 is also available as a retrofit kit (Option R15) after the purchase of your spectrum
analyzer, or as a kit 5062-8218.
Option 101 is recommended in addition to Option 105 since it significantly decreases sweep
time and therefore the resolution in the time domain.
CT2 Demodulator (Option 110)
Fbr HP 85913, HP 8593E, HP 8594E, HP 85953, and HP 8596E only. Option 110 provides
built-in demodulation capability for making CT2 transmitter measurements. It must be
used with the HP 85717A CT2-CA1 measurements personality to make frequency deviation
measurements on CT2 cordless telephone handsets and bases.
Option 110 is also available as a retrofit kit (Option R05) after the purchase of your spectrum
analyzer, or as a kit HP part number 5063-0244.
Group Delay and Amplitude Flatness (Option 111)
Fbr HP 85933, HP 8594E, HP 8595E, and HP 8596E only. Option 111 allows you to make
end-to-end and loop back measurements of group delay and amplitude flatness. It must be
used with HP 11770A Link Measurement Personality and the Option 010, Tracking Generator.
HP 11768A Group Delay and Amplitude Flatness Retrofit Kit contains both the Option 111 and
the HP 11770A Link Measurement Personality. This kit is factory retrofittable only.
Measurement Personalities, Options, and Accessories
1 O-9
