TV Sync Trigger Capability/Fast Time-Domain Sweeps and AM/FM
Demodulator (Option 301)
Fbr HP 85913, HP 85933, HP 8594E, HP 85953, and HP 85963 only. Option 301 is a combined
option made of Options 101 and 102, allowing sweep times down to 20 ,US in zero span,
enabling use of amplitude or frequency demodulation, and allowing a demodulated signal to be
listened to. See Options 101 and 102 above for more detailed descriptions.
508 to 75Q Matching Pad (Option 711)
Fbr E-Series and L-Series spectrum analyzers. This option provides a 5Ofl to 7562 matching pad
with dc block to be used on the spectrum analyzer input. The pad has a frequency range of
1 MHz to 1.8 GHz. It adapts your standard 500 spectrum analyzer to be compatible with a 753
system under test.
Option 711 is also available as HP part number 08590-60090.
Reduced Frequency Accuracy (Option 713)
For HP 85901, only. Option 713 removes the built-in frequency counter from your spectrum
analyzer. This reduces the frequency accuracy of your measurements.
Rack Mount Kit Without Handles (Option 908)
This option provides the parts necessary to mount the spectrum analyzer in an HP System II
cabinet or in a standard 19 inch (482.6 mm) equipment rack.
Option 908 is also available as a kit (HP part number 5062-4841).
Rack Mount Kit With Handles (Option 909)
Option 909 is the same as Option 908 but includes front handles for added convenience.
Option 909 is also available as a kit (HP part number 5062-4840).
User’s Guide and Calibration Guide (Option 910)
An additional copy of the HP 8590 E-Series and L-Series Spectrum Analyzers User’s Guide,
the HP 8590 E-Series and L-Series Series Spectrum Analyzers Quick Reference Guide, and the
Calibration Guide of the appropriate model number for your spectrum analyzer, are available
as a set under Option 910.
Service Documentation (Option 9 15)
Option 915 provides one copy of the assembly-level repair service guide and one copy of
the component-level repair service guide. The assembly-level repair service guide describes
assembly level troubleshooting procedures and adjustment procedures. The component-level
repair service guide includes parts lists, component-location diagrams, and schematic diagrams
for selected repairable assemblies. The manuals can be ordered separately.
BenchLink Spectrum Analyzer (Option B70)
Option B70 provides the BenchLink Spectrum Analyzer software that can be used to capture
screen images and trace data using a Personal Computer (PC). The captured information can
then be used in other PC applications, including word processing and spreadsheets.
lo-12
Measurement Personalities, Options, and Accessories
