ATTEN 10 dB
PEAK
HP859X 128
LOG
10
s LW-8 STATE 12 23 MAR l9E9
t-40 TRACE 13 15-56-45 27 MAR 1389
s AAAAA-21 STATE 18 00 21:39 28 MAR 19R9
.s-22 STATE 19 1 00 25:16 28 MAP 1389
s-l 1 STATE 20 1 00.25:39 28 MAP 1989
dPPDG DLP 21 1 08-45 57 29 MAR 198’3
dOOOm5 DLP 22 1 07.45:40 05 APR 13E9
s-222 STATE 23 1 06:41.00 07 APP 1989
t LW-22 TRACE 24 5 06:45.42 07 APP 1389
dLW-222 DLP 29 1 06 49.34 07 APR 1989
dLW-20 DLP 30 1 06 : 50.54 07 APR 1989
SA SB
I LGm5 LIMIT 31 1 09.1 1 30 10 I)CT 1989
SC FC
aTEMP-4 AMP 32 1 07.30: 11 10 OCT 1989
CORR
CENTER 27
08823 GHr SPAh 60.74 MHz
RES BW 300 kHz VBW 100 kHr SWP 20 msec
Figure 7-l. Memory Card Catalog Information
‘Ihble 7-3. Memory Card Catalog Information
2
I I
Number of kilobytes
3 Data Type
7 File name
Description
A label to identify the memory card. FORMAT CARD automatically
assigns the volume label “HP859X” to the card.
Displays the size of the memory card. 128 is the number of 256.byte
blocks or records. 128 indicates that the card is a 32-Kbyte memory
card (128 blocks x 256 bytes per block).
Indicates the type of data-trace, state, downloadable program (DLP),
limit line (LIMIT), amplitude factors (AMP), display image (DSPLY). The
data type is determined by the letter t, s, d, 1, a, or i preceding the
filename.
Indicates the physical record number of the start of the file.
Indicates number of records in the file.
Indicates the time and date of file creation.
The letter preceding the file name indicates the type of data of the file:
t = trace data, s =. state data, d = program data (downloadable
program), 1 = limit line, a = amplitude factors, i = display image. If the
data was saved using a prefix, the prefix follows the first character in
the file name. An underscore and the register number follow the prefix.
CATALOG
CARD
Requires 0ption 003 for an HP 85901, HP 8592L, or HP 8594L.
displays a catalog of the items stored on the memory card, while accessing the
memory card configuration menu.
Front-Panel Key Access: (CONFIG]
Key Descriptions 7-17
