Using Instrument Functions
Customizing the Display
Using the Split Display Feature
When using both measurement channels, you can choose to either view
both of them simultaneously on one full-size display, or use the split screen
feature.
lb use the split display feature, press @iCLE’] ?&xx Riaplay
Split; Disp FULL spHt . Figure 4-20 shows a split display.
)I: Transmission
Log Mag
10.0 dB/ Ref 0.00 dB
I I I I I I
dB
3
2
1
-1
-2
-30 I
Abs -
\.
Start 0.300 MHz Stop 3 000.000 MHz’
D2: Ref lectlon Log Mag
10.0 dB/ Ref 0.00 dB
dB
3
2
1
2
-1
-2
-3
Abs
4-51
Start 0.300 MHz
Stop 3 000.000 MHz
Figure 4-20. Split Display
