HP 8711C User Manual

I
-
I
-
Calibrating for Increased Measurement
Accuracy
Choose an Appropriate Calibration Method
To Perform a Calibration With Non-Standard
Connectors
When using a calibration kit other than one that is compatible with the
standard type-N female connectors (cal kit model number HP 85032B/E for
50 Q analyzers or HP 85036BE for 75 fl analyzers), you can either select
a connector type that is stored in the analyzer or input your own cal kit
definitions.
The following table shows the connector types that are stored in the analyzer
along with the appropriate cal kit model number.
Connector Type Cal Kit
Type-N lml 150 fit HP 850328/E
I-
Type-N lml 175 III HP 850368/E
Type-F Ifl
HP 85039A
3.5 mm HP 850330
To select the connector type by pressing ICAL) Cal KEt and then the
connector type applicable to your measurement.
If you are calibrating with type-F connectors, you must follow the procedure
in the HP 85039A Calibration Kit User Infmation.
For other connector types, the easy way to enter defmitions is to download
them from a hle on disk. Use the template program on the Example Programs
disk (DOS format) as a starting point. The format of a Cal kit file is explained
in the next section.
6-17
