Using
a
Keyboard
You can use an IBM PC-AT compatible keyboard with your analyzer. A
keyboard is useful when entering and editing names for files and directories.
It is also useful for creating and editing
IBASIC
programs (Option
lC2).
All of the analyzer front panel hardkey and
softkey
functions can be activated
from a keyboard also. See “Front Panel Control Using a Keyboard,” later in
this section.
To
Connect
the
Keyboard
To connect a keyboard, hrst turn off the analyzer. Then connect a PC-AT
compatible keyboard with a mini-DIN connector to the rear panel DIN
KEYBOARD connector. See Figure l-4 in Chapter 1 for the location of the
keyboard connector. Turn the analyzer back on after the keyboard connector
is fully inserted into the connector.
NOTE
If your keyboard has a standard (large
5-pin)
DIN connector, you will need to use a
DIN
to mini-DIN
lsmall
6-pin1
adapter to connect the keyboard to the analyzer. These adapters are available as HP part
no. 1252-4141. Contact the nearest HP sales or service office for more information.
4-93
