Using Instrument Functions
Using an External VGA Monitor
Customizing Color on an External Monitor
Although the analyzer’s built-in monitor is monochrome, you can connect an
external color monitor to the analyzer for customized viewing. Your analyzer
is equipped with a standard VGA compatible connector on the rear panel. See
Chapter 8 for information on this connector.
The analyzer’s default colors (selected by pressing @i'CTF) kre Display
Colw Qp%ions FEK~O~ Default ) were chosen for optimal viewing of
measurement data and text on an external VGA color monitor. However, you
can customize the color of various display items if desired.
To customize the color on an external display, press L-1 Make DicrpEay
Color Uptime Custom Cslars. First, select the item you want to
change by pressing the Select Item key, and then using the front panel
knob, or the ($J ($J keys to select the item you want to change. You can
also use the analyzer’s keypad to input the number of the item you want to
change. Refer to the table below to identify item numbers.
Description
Background
Text
User Graphics Pen 2
User Graphics Pen 3
User Graphics Pen 4
User Graphics Pen 5
User Graphics Pen 6
User Graphics Pen 7
Item # Description
9 Inactive Text
10 Warning Text
11 Graticule
12 Trace 1
13 Mem 1
14 Trace 2
15 Mem 2
16 Text
