Automating Measurements
Displaying Measurement Results
Customized
Measurement
Channel
Annotation
The analyzer displays measurement channel annotation above the graticule.
This annotation shows the measurement type, format,
scale/div,
and
reference level.
You may replace this annotation with your own text or eliminate the
measurement channel annotation completely. lb do so, use the following
command to enable user-defined annotation:
DISPlay:ANNotation:CHANnel[ll2]:USER[:STATe]
~OFFtOIONIl)
For example :
DISPlay:ANNotation:CHANnell:USER ON
l To specify the string to be displayed use the command:
DISPlay:ANNotation:CHANnel[ll2]:USER:LABel[:DATA] <STRING>
For example:
DISP:ANN:CHANl:USER:LABel ‘1:
SuperNotch
filter, test
#3’
l To restore the default measurement channel annotation, use:
DISPlay:ANNotation:CHANnell:USER OFF
l To turn the measurement channel annotation on or off press
(jj)
Mom
DdspEay
Annotation Options
Ideas
Annot
ON
off or use
these SCPI commands:
DISP:ANN:CHAN[ll2]
ON
DISP:ANN:CHAN[l12]
ON
7-68
