Making Measurements
Measuring Transmission Response
)I:
Transmlsslon
Log Mag
20.0
dB/
Ref -60.00 dB C
D2:
off
1
Chl:
Mkrl 69.26
MHz
-3
3
-120
-140
Abs
Start 0.300
MHz
Stop 3 000 000
MHz
Figure 3-5. Example of a Transmission Measurement Display
5. See “Using Markers” in Chapter 4 for more detailed information on using
markers to interpret measurements.
NOTE
For the measurement to be valid, input signals must fall within the dynamic range of the analyzer. See
Chapter 5 for techniques to increase the dynamic range of the analyzer.
3-23
