Getting Started
Performing the Operator’s Check
Make
a
Transmission
Measurement
1. Connect the equipment as shown in Figure 2-6. Use a known good cable
such as the one that was supplied with your analyzer.
NETWORK ANALYZER
RF OUT
U
RF
Figure 2-6. Equipment Setup for Transmission Measurement
2.
Press
cm]
[ml
. 1
titer
3.
Press [POWER)
@
[ENTER).
4. Verify that the data trace falls within
f0.5
dB
of 0
dB.
See Figure 2-7 for a
typical result.
2-15
