Automating Measurements
Displaying Measurement Results
Customized X-axis Annotation
X-axis annotation consists of one or two lines of information that appear
below the graticule.
By default, the X-axis annotation displays the stimulus frequencies (default
resolution is kHz), or powers if in power sweep. It can be, however,
customized using SCPI commands to show your own start and stop x-axis
values and units. For example, when measuring mixers which introduce a
frequency offset, you can annotate the frequencies at the output of the mixer.
l lb turn on user-defined X-axis annotation, use the command:
DISPlay:ANNotation:FREDuency[lj2]:USER[:STATe] (OFFIOIONII)
For example:
DISPlay:ANNotation:FREDuencyl:USER ON
l To specify your start and stop values, use:
DISPlay:ANNotation:FREQuency[ll2]:USER:STARt <num>
DISPlay:ANNotation:FREQuency[ll2l:USER:STOP <num>
The value Cnum> must be between -10,000 and 10,000. For example:
DISPlay:ANNotation:FREDuencyl:USER:STAR -100
DISPlay:ANNotation:FREQuencyl:USER:STOP +lOO
0 lb specify a custom suffix, use:
DISPlay:ANNotation:FREtJuency[ll2] :USER:SUFFix[:DATA] <STRING>
for example:
DISPlay:ANNotation:FREQuencyl:USER:SUFFix ‘uV’
The suffix can be up to 3 characters long.
l lb turn the X-axis (frequency) annotation on or off, press (-1
Mwa Displa-y Amrrtatirra Options Fmq Annot ON off , or use
these SCPI commands:
_I
DISP:ANN:FREQ[l12] ON
7-66
