Measuring
Reflection
Response
This section uses an example measurement to describe how to calibrate
for and make a basic reflection response measurement. In this example, a
bandpass filter like the one that was supplied with your network analyzer is
used.
Enter
the
Measurement
Parameters
Press the following keys on the analyzer:
l-w1
(MEAS)
Bef
Lectian
NOTE
This example measurement uses the default instrument parameters for a reflection response
measurement. If your particular reflection measurement requires specific parameters (such as frequency
range, source power level, number of data points, and sweep time), enter them now
3-24
